The Badland Batteries BB-012601PD battery cell has 16000mAh capacity, energy density of 240Wh/kg and burst discharge rate of 40C. All battery cells are built in the U.S.A.
BB-012601PD
Specifications
| Item | Parameter of Cell |
| Energy Density | 240Wh/kg |
| Nominal Capacity | 16000mAh |
| Nominal Voltage | 3.9V |
| Internal Impedance | ≤2mΩ (AC@1kHz) |
| Standard Discharge Current | 3200mA |
| Max. Continuous Discharge Current | 420A (20C) |
| Burst Discharge Current | 640A (40C) |
| Discharge Cut-off Voltage | 3.0V |
| Standard Charge Current | 3200mA |
| Max. Constant Charge Current | 16000mA |
| Charging Cut-off Voltage | 4.45V |
| Product Size | 9.6mm x 94mm x 129mm |
| Weight | 262g |
| Operating Temperature Range | Charge: 10° - 45°C (50° - 113°F) Discharge: -20° - 60°C (-4° - 140°F) |
American-powered batteries.
Badland Batteries designs and manufactures batteries for drones and UAS platforms. Our technology delivers high energy density, high discharge capability, and rugged durability, giving UAS the endurance, power and resilience required for mission-critical operations. Badland isn’t just another battery supplier. We are a full-scale, end-to-end NDAA-compliant battery cell and pack engineering hub.
Features & Benefits
Made in the United States
More power for larger energy demands
Mass production at scale
Made with non-FEOC raw materials
NDAA compliant
UL 1642 compliant
ISO 9001 certified
Let’s talk batteries
What type of system are you using and what are your battery needs? We love talking about how our batteries can improve your existing systems. Reach out to us with any questions you might have.
Performance you can trust.
Manufacturing high-energy density batteries at scale
We’re transforming how batteries power the world. By enabling longer range, faster charging, and higher payloads, we’re driving the future of electric mobility — across air, land, and sea.
